2-Rail Junction Box-2

Alpha Products, Inc. 351 Irving Drive, Oxnard, CA 83030, USA
Tel: 805-981-8666 / Fax: 805-988-6555 / Contact Us

Part number

Diodes
Rating

Connector
type

JB Rated Current

Connector dia.
(mm)

Cable size
(sq. mm)

Cable length
(m)

3SO/JBZ9

No diode

Female

15A

4.0

2.5

0.3

3SO/JBZ8

No diode

Male

15A

4.0

2.5

0.3

3SO/JBM7

10A @1000V

Female

7A

4.0

2.5

0.75

Specifications

Cable Size

 2.5 sq.mm (14 AWG)

Rated Voltage

 600V

Contact Resistance

 5 mOhm max

Protection Class

 II

Housing Material

 PPO

Terminal Material

 Copper, tin plated

Protection Degree

 IP65 (IEC 60529) / IP67 (with potting)

Flame Class

 UL94V-0

Temperature Range

 -400C to +850C

Box Size

 38 x 60 x 15 mm

Description

 For thin film & flexible module
